R32 45mm Threaded Button Bit Flat Face Tungsten Carbide Hard Rock Drilling Tool
| MOQ: | 10 Pieces |
| Price: | USD 25-38/ Piece |
| Standard Packaging: | Export-grade corrugated carton with foam insert, 10 pieces per carton, customized branding available |
| Delivery Period: | 5-7 working days for stock, 15-25 days for production |
| Payment Method: | T/T,L/C,PayPal,Western Union |
| Supply Capacity: | 5000 Pieces per Month |
R32 45mm Threaded Button Bit
,R32 45mm Tungsten Carbide Button Bit
,R32 Hard Rock Drilling Tool
R32 45mm Threaded Button Bit for Rock Drilling
The R32 45mm threaded button bit is a top hammer rock drilling tool engineered for high-efficiency drifting, tunneling and underground bench drilling. Manufactured from high-grade alloy steel with ultra-wear-resistant tungsten carbide inserts, this 45mm drill bit delivers efficient impact energy transfer, fast penetration rates and an extended service life in medium to hard rock formations.
Product Overview
Designed with a flat face (FF) profile and an optimized flushing hole configuration, the R32-45mm button bit ensures excellent hole straightness, efficient cuttings evacuation and reduced drill string wear. It is an ideal choice for modern hydraulic rock drills and R32 drifter rods.
Main Applications
- Underground Tunneling & Drifting: Precision hole drilling for tunneling projects and mine development.
- Rock Bolting & Anchoring: Fast drilling for roof support installation in mining and civil engineering.
- Dimensional Stone Quarrying: Clean and straight hole drilling in granite, limestone and marble quarries.
- Bench Drilling: Small-hole benching and production drilling in open-pit or underground mining operations.
Key Features & Advantages
- High-Grade Carbide Quality: Premium tungsten carbide buttons provide high impact resistance and excellent resistance to abrasive wear.
- Advanced Thermal Insertion Technology: Carbide inserts are thermally pressed into CNC-machined body sockets to prevent button dropout during high-impact operations.
- Optimized Flushing System: Strategically placed front and gauge flushing holes enable rapid removal of rock debris, preventing bit re-drilling and overheating.
- High Energy Transfer: Seamless compatibility with R32 drifter rods and top hammer hydraulic rock drills.
- Cost-Effective Performance: Lower cost per meter of drilling through extended service intervals and excellent wear resistance.
Product Specifications
| Product Name | R32-45mm Threaded Button Bit |
| Thread Type | R32 (Standard Top Hammer Thread) |
| Bit Diameter | 45 mm (1 3/4 inch) |
| Face Design | Flat Face (FF) / Flat Profile |
| Body Type | Standard Skirt (Retrac Optional) |
| Button Configuration | 9 Buttons (6 Gauge + 3 Front) / 7 Buttons Optional |
| Carbide Shape | Spherical (Dome) / Ballistic / Semi-Ballistic |
| Carbide Dimensions | Gauge: 6 x 10 mm; Front: 3 x 8 mm (Standard) |
| Flushing Holes | 3 Front Holes + 1 Side Hole (Customizable) |
| Body Material | Premium Structural Alloy Steel (45CrNiMoV / 35CrNiMoV) |
| Process / Heat Treatment | Full CNC Machining + Industrial-Grade Thermal Heat Treatment |
| Approx. Net Weight | ~ 0.8 kg |
| Matched Drill Rods | R32 Hex/Round Drifter Rods (R32-R28, R32-T38, etc.) |
FAQ
Q: What is the R32 threaded button bit used for?
A: It is used for top hammer drilling in underground tunneling, drifting, rock bolting, dimensional stone quarrying and bench drilling.
Q: What is the bit diameter?
A: The standard diameter is 45 mm (1 3/4 inch) with R32 thread connection.
Q: Can the button configuration be customized?
A: Yes. 9-button and 7-button configurations, carbide shapes and flushing hole layouts are customizable according to your rock conditions.
